· Pipe connection type:M5, G1/8...G1/2 NAMUR:G1/4,G3/8
· High flow rate, robust and durable
· Standard LED light junction box available in 3/2, 5/2, and 5/3 configurations
· The easy-to-install floor-mounted NAMUR version is available
· IP65 protection rating
|
Valve width
|
Option
|
|
18mm-M5 or G1/8
|
A
|
| 22mm-G1/4 |
B
|
| 27mm-G3/8 |
C
|
| 34mm-G1/2 |
D
|
|
Function
|
Option
|
|
3/2
Normally open
|
3
|
|
3/2
Normally closed
|
4
|
|
5/2
|
5
|
|
5/3
Mid-closed
|
6
|
|
5/3
Mid-exhausted
|
7
|
|
5/3
Mid-pressurised
|
8
|
|
Drive Type
|
Option
|
|
Electrical control/
Electrical control
|
11 |
| Electrical control/
Spring control
|
17 |
|
Coil
|
Option
|
| 15mm(18mm Valve width) | D-C |
| 22mm | A-A |
|
Interface size
|
Option
|
| M5(18mm valve width) | 5 |
| G1/8(18mm valve width) | A |
| G1/4(22mm valve width) | B |
| G3/8(27mm valve width) | C |
| G1/2(34mm valve width) | D |
| G1/4 NAMUR(27mm valve width) | E |
| G3/8 NAMUR(27mm valve width) | F |
| 1/8 NPT(18mm valve width) | P |
| 1/4 NPT(18mm valve width) | R |
| 3/8 NPT(18mm valve width) | S |
| 1/2 NPT(34mm valve width) | T |
| 1/4 NPT NAMUR (27mm valve width) Note1） | U |
| 3/8 NPT NAMUR (27mm valve width) Note1） | V |
|
Manual
|
Option
|
|
Rotationand locking
|
2 |
|
Voltage(VPL33B/C/D)
|
Option
|
| 24V DC | 13J |
| 24V AC | 14J |
| 110V AC | 18J |
| 220V AC | 19J |
| 240V AC | 20J |
|
Voltage(VPL33A)
|
Option |
| 24V DC | 13F |
| 110V AC | 18F |
| 220V AC | 19F |
Note1) : The 3/2 NAMUR version canbe obtained by adding a conversionplate to the5/2 NAMUR version.
The automotive industry is among the earliest and most highly automated sectors. As a core component in automated control systems, the valve island enables precise regulation of industrial robot pneumatic gripper, dual-circuit water and air systems, fixtures, and related equipment through integrated and modular design. Its key features include:
• Integrated electro pneumatic platform
• Diverse power, communication, and sensor interfaces
• Multiple communication protocols
• Digital and analog inputs/outputs
• WIFI (optional)
