· Displays real-time flow rate and configuration parameters
· Supports 24V solenoid valve drive with automatic shut-off upon flow anomaly detection
· Flow configuration data displayed on LED display
· Real-time flow rate data is continuously displayed
· Flow data measured via supply and return line flow sensors for differential analysis
|
Display device
|
Option
|
|
Digital display
|
V2
|
|
Pulsing signal
|
S1
|
|
485 signal
|
S2
|
|
Bus protocol
|
Option
|
|
PROFINET
|
PN
|
|
DeviceNet
|
DN
|
|
EtherNet/IP
|
EP
|
|
Water supply diameter
|
Option
|
|
1/2 Caliber
|
1/2
|
|
3/4 Caliber
|
3/4
|
|
Material quality
|
Option
|
|
Metal
|
M
|
|
Plastics
|
P
|
|
Option (plastic)
|
Option |
|
Temperature
|
T |
Note: Select the appropriate configuration based on your specific application requirements. For any questions, please contact technical support.
The automotive industry is among the earliest and most highly automated sectors. As a core component in automated control systems, the valve island enables precise regulation of industrial robot pneumatic gripper, dual-circuit water and air systems, fixtures, and related equipment through integrated and modular design. Its key features include:
• Integrated electro pneumatic platform
• Diverse power, communication, and sensor interfaces
• Multiple communication protocols
• Digital and analog inputs/outputs
• WIFI (optional)
